Product Center
Industrial Electric Heater Products
Divided by heating target into liquid, gas and surface heating — 14 product series in total. Each offers standard models and custom builds to your process; the parameters shown are typical ranges and the technical agreement prevails.
18 models
Flanged HeatersFlanged Immersion Heater
HYF Series
A bundle-type immersion heater with a standard flange mounting interface, suited to pressurized vessels and high-power process heating, and withdrawable as a complete assembly for service.
- Power
- 3 – 500 kW
- Temp
- Ambient – 600°C
Screw Plug HeatersScrew Plug Immersion Heater
HYS Series
A compact heater that screws into the vessel wall; the small bore suits low- to medium-power tanks and pipe tracing.
- Power
- 0.5 – 36 kW
- Temp
- Ambient – 400°C
Circulation & Inline HeatersInline Circulation Heater
HYC Series
Inline vessel heating—medium flows through continuously and heats up, integrating temperature control, over-temperature protection, and flow interlock for turnkey connection to piping.
- Power
- 6 – 300 kW
- Temp
- Ambient – 350°C
Immersion HeatersCoil Immersion Heater
HYW Series
Helically arranged bundle gives longer heated length within a limited immersion depth, suited to deep tanks and high power density.
- Power
- 2 – 120 kW
- Temp
- Ambient – 550°C
Over-the-Side HeatersOver-the-Side Heater
HYO Series
Suspended from the tank rim without penetrating the wall; the whole unit can be lifted out for tank change or cleaning.
- Power
- 1 – 60 kW
- Temp
- Ambient – 120°C
Tubular Heating ElementsU-Shaped Tubular Heating Element
HYT Series
General-purpose heating element of resistance wire, MgO powder, and metal sheath; bendable into any shape.
- Power
- 0.5 – 15 kW
- Temp
- Ambient – 800°C
Finned Tubular HeatersFinned Tubular Heating Element
HYF-T Series
Fins wound/welded over the bare tube extend heat-transfer area 4–8×—the preferred structure for gas heating.
- Power
- 0.5 – 20 kW
- Temp
- Ambient – 550°C
Duct HeatersDuct Air Heater
HYD Series
Heating section inside rectangular or round ducts, with over-temperature protection and SCR control for continuously adjustable outlet temperature.
- Power
- 3 – 600 kW
- Temp
- Outlet air temperature ≤ 300°C
Infrared Radiant HeatersMedium-Wave Infrared Heater
HYI Series
Radiant heating directly to the workpiece surface—fast heat-up, low thermal inertia—for coating drying and plastic forming.
- Power
- 0.5 – 6 kW/element
- Temp
- Element surface 600 – 900°C
Band HeatersCeramic Band Heater
HYB Series
Ceramic blocks strung in a metal shell—high-temperature and thermal-shock resistant—for injection and extrusion barrels.
- Power
- 0.3 – 12 kW
- Temp
- Up to 650°C
Band HeatersMica Band Heater
HYB-M Series
Mica-insulated, thin-profile, low-cost—for low/medium-temperature barrel and pipe wrap heating.
- Power
- 0.2 – 8 kW
- Temp
- Up to 350°C
Strip HeatersFinned Strip Heater
HYS-F Series
Strip element with added fins for oven and duct air heating; easy to install and replace.
- Power
- 0.3 – 6 kW
- Temp
- Up to 450°C
Cartridge HeatersHigh-Density Cartridge Heater
HYC-H Series
Cylindrical element from Φ3 mm, power density up to 30 W/cm², for localized mold and hot-runner heating.
- Power
- 0.05 – 3 kW
- Temp
- Up to 750°C
Silicone Rubber HeatersSilicone Drum Heater
HYG Series
Flexible silicone band wraps the drum for uniform heating and viscosity reduction—solving winter oil that will not pump or flow.
- Power
- 1 – 5 kW
- Temp
- Up to 200°C
Temperature Control PanelsExplosion-Proof Temperature Control Panel
HYP Series
Flameproof enclosure integrating temperature control, protection, and power distribution for petrochemical, oil & gas, and other explosive environments.
- Power
- 5 – 200 kW
- Temp
- Controlled object ≤ 600°C
Temperature Control PanelsSCR Power Control Panel
HYP-S Series
Phase-angle or zero-crossing control with continuously adjustable output, reducing grid inrush and temperature fluctuation.
- Power
- 10 – 400 kW
- Temp
- Controlled object ≤ 1000°C
Immersion HeatersHigh Power Immersion Heater
HYI Series
Multiple bundles in parallel for base-load heating of large tanks, water-treatment basins, and district-heating systems.
- Power
- 20 – 800 kW
- Temp
- Ambient – 550°C
Circulation & Inline HeatersThermal Oil Circulation Unit
HYC-OIL Series
Atmospheric high-temperature heating—a steam-boiler alternative—for stable heat to reactors, presses, and drying lines.
- Power
- 30 – 1000 kW
- Temp
- Up to 350°C
Send us your operating parameters and get a selection and quote within 48 hours
Medium, temperature, power and mounting method — four details are enough to start the design. Complex duties are handled directly by our engineers.
